Rigid PCB Capacity

Item

Description

Remark

Layer

1- 20Layers (FR- 4, FR- 406, 370 HR)
1- 2Layers (Rogers, Aluminum/ Copper Base, TEFLON)

Material

FR- 4, FR- 406, 370 HR; Rogers4003; Rogers4350
Aluminum and Copper base;Teflon

Finish Thickness

Finish Thickness: 0.008" - 0.275" (0.2mm- 7mm)

Min Thickness

2- layer: 0.008" (0.2mm)
4- layer: 0.016" (0.4mm)
6- layer: 0.024" (0.6mm)
8- layer: 0.032" (0.8mm)
10- layer: 0.04”(1mm)
More than 10layers (0.5Xnumber of layers X0.008”)

Surface Finishing

Lead Finishing: HASL, HASL+Gold finger
Lead- free Finishing: Lead- free HASL, ENG Gold; OSP, Immersion silver

Special Process

Impedance board (request as± 10%)
High TG / halogen- free/ / halogen- free & High TG board

Max / Min Board Size

1- 2Layers Max : 59" x 50" / Min: 0.2" x 0.2"
4- 6Layers Max : 32" x 28" / Min: 0.4" x 0.4"
8- Layers Max : 30" x 24" / Min0.4" x 0.4"

Min Trace
Width / Min Clearance

Inner Layers(trace width/clearance)
0.5oz: 4/ 4mil
1oz: 5/ 5mil
2oz: 5/ 7mil
3oz: 7/ 8mil
4oz: 10/ 10mil
5oz 12/ 12mil
6oz/ 15/ 12mil

Outer Layers(trace width/clearance)
1/ 3oz- Hoz: 4/ 4mil
1oz: 5/ 5mil
2oz: 5/ 7mil
3oz: 7/ 8mil
4oz: 10/ 10mil
5oz: 12/ 12mil
6oz: 15/ 12mil

Partial 3mil line width and 4mil clearance is allowed

Aspect Ratio

1: 10

Board Thickness	Min Hole Size
8mil - 62mil	6mil
80mil	8mil
93mil	9mil
125mil	12mil

Min Hole Ring

Inner:
0.5oz: 5mil
1oz: 6mil
2oz: 8mil
3oz: 12mil
4oz: 15mil
5oz: 18mil
6oz: 20mil

Outer:
1/ 3oz -0.5oz: 4mil
1oz: 5mil
2oz: 7mil
3oz: 10mil
4oz: 16mil
5oz: 18mil
6oz: 20mil

Copper Thickness

Inner: H0.5oz, 1oz, 2oz, 3oz, 4oz, 5oz. 6oz
Outer: 1/ 3oz, 0.5oz, 1oz, 2oz, 3oz, 4oz, 5oz, 6oz

Standard Stack Up

4- layer:

6- layer:

8- layer:

10- layer:

Min Hole Size and Tolerance

Min Finish Hole: 6mil
Hole Tolerance: ±3mil

Thickness of Plating Layer

HASL:
Copper Thickness: 20um -35um	Tin 5 -20um
Immersion Gold:
Nickel 100u" -200 u"	Gold 2u" -4u"
Hard Plated Gold:
Nickel 100u" -200 u"	Gold 4u" -8u"
Golden Finger:
Nickel : 100u" -200 u"	Gold : 5u" -15u"
Immersion Silver: 6u" -12u"
OSP: Film 8u" -20u"

Solder Mask Color

Glossy: Green, Black, Red, Yellow, White, Purple, Blue

Matt: Green, Black

Solder Mask Resolution

Solder Mask Thickness:	0.2mil -1.6mil
Solder Dam:	Green 7mil /Other Color 8mil
Solder Mask Hole Plug Diameter:	10mil -25mil

Silk Screen Color

White, Black

Profile

Punch Tol: ±5mil
CNC Tol: ±5mil
V- CUT Tol: ±10mil
Bevel Edge: ±5mil

Slot Min: 32mil
Slot Min: 32mil
Angel: 15°, 20°, 30°, 45°, 60°

Bow and Twist

SMT ≤0.75%
None SMT ≤1%

Accept Standard

IPC Class 2; IPC Class 3; ISO9000
